Operating manual and inspection booklet
Overview
92 3435216
is illuminated if the supply voltage for the heater is selected.
The seven-segment display indicates the switching
condition.
6 "Water pump" symbol
is illuminated if the water pump is selected. The seven-
segment display indicates the switching condition.
7 "Outside temperature" symbol
is illuminated if the outside temperature is selected. The
seven-segment display indicates the outside temperature.
8 "Inside temperature" symbol
is illuminated if the inside temperature is selected. The
seven-segment display indicates the outside temperature.
9 Seven-segment display
indicates the switching conditions and information such as
temperature, etc.
10 "12 V supply symbol
is illuminated when the 12 V supply is switched on.
11 "Living room battery" symbol
is illuminated if the living room battery is selected.
Information such as a charge/discharge voltage can be
indicated on the seven-segment displays.
12 "Starter battery" symbol
is illuminated if the starter battery is selected. Information
such as a charge condition can be indicated on the seven-
segment displays.
13 "Water tank" symbol
is illuminated if the water tank is selected. The seven-
segment display indicates the filling level.
14 "Waste water tank" symbol
is illuminated if the waste water tank is selected. The seven-
segment display indicates the filling level.
15 "Clock" symbol
is illuminated if the clock is selected. The time is indicated in
the seven-segment display. Here, the time can also be set
or adjusted.
NOTE
For detailed information, refer to the operating
instructions of the relevant manufacturer!
