Operating manual and inspection booklet
Overview
94 3435216
Preparing the motorhome for a period of non-use
Non-use is defined as the disconnection of the 12 V charging
system and all consumers from the batteries. Excluded from this
are:
Devices that charge the living room area are still connected
(e.g., solar controllers).
The operating and control panel described here
"Living room battery" symbol
Implementing a period of non-use
1. Switch off the 12 V power supply.
The "12 V ON" symbol extinguishes.
2. Press and keep the rotary/pushbutton depressed.
After approx. 10 sec the living room symbol and the "OFF"
light on the seven-segment display flashes.
3. Release the rotary/pushbutton.
The vehicle is in a period of non-use.
Ending a period of non-use
1. Press and keep the rotary/pushbutton depressed.
After approx. 5 sec the living room symbol and the "ON" light
on the seven-segment display flashes.
2. Release the rotary/pushbutton.
The '12 V ON" is illuminated – the 12 V power supply of the
living area is switched on.
The vehicle is now ready for use again.
Power connection
Fig. 60: Electrical connections
The connection to the 230 V power supply can be found outside
the vehicle along the side wall.
The 3-pole CEE plug installed permanently in the motor home is
used as connection.
NOTICE
Before travelling to foreign countries, obtain
information about the plug and connector systems
used at your destination. Suitable adapters are
commercially available.
