WSDA
®
-2000 User Manual
Value Definition Applicable Packet
tick
Packet tick number
LDC (v1,v2), Syncrhonized Sampling (v1,v2),
Derived LDC (v1),Derived Syncrhonized Samp-
ling (v1)
noderssi
RSSI value of node
Syncrhonized Sampling (v1,v2),Derived Syn-
crhonized Sampling (v1), Asynchronous (v1),
Asynchronous Digital and Analog (v1), Structural
Health (v2), Diagnostic (V1)
Table 7 - Data Channel Definitions
The following table summarizes the Diagnostic Channel definitions.
Value Definition
current_state
Current state of the node
idle_time
Time the node spends in idle
sleep_time
Time node spends in sleep
active_time
Time node spends actively sampling
inactive_time
Time nodes spends inactive
reset_counter
Number of resets
lowBatteryFlag
Low battery warning
sweepIndex
Current sweep index
badSweepCount
Number of bad sweeps (discarded data)
totalTx
Total transmissions
totalReTx
Total transmission retries
droppedPackets
Number of dropped packets
bit
Built in test results
eventindex
Index for number of events
extPwr
External power flag
intTmp
Internal temperature
syncRtry
Number of synchronization retries
syncFail
Number of synchronization failures
secSinceSync
Time since last synchronization
Table 8 - Diagnostic Channel Definitions
30
