WSDA
®
-2000 User Manual
9.1.1 Range Test
After establishing communication between node and gateway, use the range test feature in
SensorConnect to monitor the signal strength and to optimally position the nodes, gateway, and
antennae for installation. Maximum achievable range is determined by the gateway and node
power settings (found in the device Configure menu) and is highly dependent on the physical
environment surrounding the devices.
1. Select the node name > Range Test
Figure 56 - Range Test Menu
2. RSSI isa measure of signal strength between the node and the base station. A higher
RSSI value (closer to zero), will result in better node to base station communication.
Reliable communication can be achieved with a signal strength greater than -75 dBm, in
the absence of radiofrequency interference. Position the node and gateway antennas
where the best RSSI value is observed.
Figure 57 - Range Test Statistics
70
