4.2.2 Data Alias Definitions
The names of data the sensor network produces and the WSDA can push onto the CAN bus are
defined below. All data is in big-endian format unless otherwise noted. Some data channels have
fixed sizes or depend on the node settings. Note: The Payload field of the Broadcast Message
Menu will also suggest values based on user-set configurations. To view the full list, select Payload
and hold while pressing the down arrow on the keyboard ( See CAN J1939 Output on page 22 ). For
Packet definitions and details on the data included in each packet, go to: Github.
Value Definition Applicable Packet
hist
Histogram
angle1 through
angle16
The angle for which data is
being collected
ch1 through ch16
Raw data channels (ex. ch4, is
the fourth channel of data)
LDC, Synchronized Sampling (v1, v2)
dg1 through dg16
Digital channels Asychronous Digital Only
angleid
Angle ID specified in the his-
togram packet
Structural Health (v1)
uptime
Uptime as specified in the
histogram packet
Structural Health (v1)
life
Fatigue life used as specified in
the histogram packet
Structural Health (v1,v2)
bin1 through bin21
Individual bins of histogram Structural Health (v1,v2)
binlowbound
Low end of stress histogram
starts at as specified in the his-
togram packet
Structural Health (v1,v2)
binsize
Size of each bin as specified in
the histogram packet
Structural Health (v1,v2)
proc_rate
Sample rate of data behind the
histogram
Structural Health (v2)
angStr1 through
angStr16
Strain for an angle
Raw Angle Strain Specific Angle Mode, Dis-
tributed Angle Mode
utcseconds
Seconds portion of timestamp
in data packet
Synchronized Sampling (v1, v2)
utcnanoseconds
Nanoseconds portion of
timestamp in data packet
Synchronized Sampling (v1, v2)
rms1 through rms16
RMS value of specified chan-
nel (ex. rms1 is rms value of
channel 1)
Derived LDC Packet (v1), Derived Synchronized
Sampling Packet (v1)
ptp1 through ptp16
Peak-to-peak value of specified
channel
Derived LDC Packet (v1), Derived Synchronized
Sampling Packet (v1)
ips1 through ips16
Velocity of specified channel in
inches per second
Derived LDC Packet (v1), Derived Synchronized
Sampling Packet (v1)
cf1 through cf16
Crest factor for specified chan-
nel
Derived LDC Packet (v1), Derived Synchronized
Sampling Packet (v1)
samplerate
Speed of data sampling
LDC (v1,v2), Syncrhonized Sampling (v1,v2), Stru-
tural Health (v1,v2), Derived LDC (v1),Derived
Syncrhonized Sampling (v1)
