12.2 Operating Specifications
Parameter Specifications
General
Processor ARM
®
Cortex
™
A8, 1 GHz
Operating system Linux
Connectivity
Ethernet IEEE 802.3 10/100 Mbps, IEEE 802.15.4 and
Proprietary wireless, J1939 CAN (output only), and USB
2.0 virtual Ethernet port
Internet standards HTTP, HTTPS,TCP/IP, UPnP,UDP
IP assignment IPV4 Static or DHCP
Data storage memory 4 G bytes Micro SD (optional upgrade to 8 or 16 GB)
Time synchronization
Network time protocol (NTP), Real time clock (RTC), last
used, manual entry
CANJ1939 Output
J1939 Bit Rate 250 K bps, 500 K bps, 1 M bps
J1939 Source Static or dynamic via SAE Name
J1939 Destination Static or SAE Name
J1939 Modes
Tunnel data to destination using PGN 0xEF00, or
broadcast data values using PGNs 0xFF00 – 0xFFFF
Standard bus termination 120 Ω
Sampling
Supported node sampling modes
Synchronized, low duty cycle, continuous, periodic burst,
event-triggered, and datalogging
Synchronization beacon interval
1 Hz beacon provides ± 50 μsec node-to-node
synchronization
Synchronization beacon
stability
± 5 ppm
Network capacity
Up to 2000 nodes per RF channel (& per gateway)
depending on number of active channels and sampling
settings. See system bandwidth calculator:
http://www.microstrain.com/configure-your-system
Operating Parameters
Wireless communication range
Typical* Ideal**
LXRS 1 km 2 km
LXRS+ 400 m 1 km
Radio frequency (RF)
transceiver carrier
License-free 2.405 to 2.480 GHz with 16 channels
RF communication protocol IEEE 802.15.4 and Proprietary
RF transmit power
User-adjustable from 0 dBm to 20 dBm. Power output
restricted regionally to operate within legal requirements
Power source
9.0 to 30.0 V dc (universal 15 V dc, 1.3 A AC/DC
converter included in starter kit)
Power consumption 2850 mW (max), 2400 mW (typ) @ 15 V
Operating temperature -40 °C to +85 °C
Physical Specifications
Dimensions 147 mm x 110 mm x 23 mm without antenna
Weight 343 grams
Enclosure material Black anodized aluminum
Integration
Connectors USB, RJ45 jack, 26 pin multi-port, 2.1mm power jack
Communications cable USB, Ethernet (CAT6 cable included in starter kit)
Compatible nodes All LORD Sensing LXRS
®
and LXRS+ nodes
