Replacing
the
Hard
Drive
19
19.2
Installing
a
New
Hard
Drive
CAUTION
Make
sure
that
the
system
is
OFF
and
the
power
adapter
is
disconnected
before
removing/installing
a
hard
drive.
T
o
install
a
new
hard
drive:
1.
Insert
the
2
hard
drive
screws
closest
to
the
SA
T
A
and
power
ports
on
the
hard
drive
and
tight-
en
them
half
way
.
2.
Power
off
the
system,
and
unplug
all
cabling
from
the
system.
3.
Turn
the
recorder
over
.
Remove
the
bottom
panel
screws
(6×).
#LX40011
1;
r
.
5.0/56647/56647;
en-US
100
107
109
