Using the Main Menu15
To access the main menu:
• From the Live View display, right-click to open the Quick Menu, then click Main Menu.
OR
• Click
on the Navigation Bar, then click Main Menu.
15.1 Main Menu’s Navigation Bar
The Main Menu’s Navigation Bar can be found along the top of the settings display which allows
easy access to different settings within the Main Menu.
To show the Main Menu Navigation Bar:
• Click on any of the main menu’s settings.
1. Playback: Opens the Playback Menu. This allows you to search for video recordings saved
on the recorder’s hard drive. For details on using the Playback menu, see 9 Playback, page 23
2. Events: Set preferences for events such as video loss, motion detection, Person/Vehicle detec-
tion, Face Detection, Face Recognition, and system warnings. The Events menu is also used to
set preferences for deterrence cameras.
3. Backup: Backup video files to external USB flash drive (not included).
4. Display: Set the system’s monitor resolution, configure Sequence mode, and other display
settings.
5. Camera: Configure image settings, recording parameters, channel overlay, and privacy
masking.
6. Network: View and configure network options, including setting a dynamic or static IP ad-
dress. For full instructions on configuring network options, see 15.7.1 Selecting DHCP or
Static IP Address (TCP/IP), page 67.
7. System: Configure general system settings, such as date & time, time zone, and DST.
#LX400111; r. 5.0/56647/56647; en-US 53
