Lorex D861 Series User Manual

Using the Main Menu15
6. Configure the following:
• Type: Select the address type.
• IP Address: Enter a single IP address for the selected filter type.
• Start Port: The port you want to open.
• End Port: The port you want to end at.
7. Click OK.
8. Click Apply.
15.8.5 Configuring IP Filter — Sync Time
Configure permissions for external IP addresses that are permitted to sync the recorder’s time.
To configure the IP filter:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click SYSTEM, click the Security tab, then click Sync Time-Whitelist on the top panel.
3. Click to enable ( ) / disable ( ) the selected filter type.
4. Click Add.
#LX400111; r. 5.0/56647/56647; en-US 76
