Using the Main Menu15
To configure Sequence mode:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click DISPLAY, then click the Sequence tab.
3. Click to enable ( ) / disable ( ) Sequence mode.
NOTE
• Enabling Sequence mode is not necessary for configuration.
• You can also enable Sequence mode from Live View by clicking
on the Navigation Bar, or by right-
clicking to open the Quick Menu and clicking Sequence.
4. Enter the time in seconds to remain on each channel or split screen during Sequence mode.
5. Choose how many channels will appear on screen when Sequence mode is triggered by mo-
tion detection (must be configured separately — see , page for details).
6. Select a viewing mode to configure. It is recommended to start with View 1 and make your
way to View 9. By default, all viewing modes are included in the Sequence mode cycle.
7. Configure the order of channels shown on screen for each viewing mode. Uncheck channels /
channel groups that you want to remove from the Sequence mode cycle.
8. Click Apply.
15.6 Camera
Configure image settings, recording parameters, channel overlay, and privacy masking.
15.6.1 Adjusting Camera Image Settings
Adjust the color and image quality settings of your cameras.
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
#LX400111; r. 5.0/56647/56647; en-US 62
