Motion Detection11
In addition to general motion detection, the system supports smart Person and Vehicle detection.
Both types of detection can be configured using the menu shown below.
11.1 Configuring Motion Detection
Set preferences for motion detection on each channel, and select channels you want to enable
smart Person and Vehicle detection on.
To configure motion detection:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click EVENTS. Click the Event Settings tab on the side panel, then Motion Detect on the
top panel.
3. Select a camera to configure motion detection for.
4. Click to enable (
) / disable ( ) motion detection on the selected channel.
#LX400111; r. 5.0/56647/56647; en-US 33
