Using the Main Menu15
• Connect a USB flash drive (not included) to a free USB port on the unit with an exported sys-
tem configuration (see 15.8.6 Save System Settings to a USB Flash Drive, page 77 for full
details).
To import system settings:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click INFORMATION, click the Update/Reset tab, then click Import/Export on the top
panel.
3. Under Device Name, select the USB device where a system configuration has been saved.
4. Click the folder with the configuration files you would like to restore. Configuration file fold-
ers are labeled Config and then the time and date the configuration was saved (e.g., Config_
20200611133747).
5. Click Import to save your current system configuration.
15.12 Copying Settings to Another Channel
Some areas of the main menu allow you quickly copy over the settings from one channel to one or
multiple other channels on the system.
To copy channel settings:
1. Configure at least one channel to your preference.
2. Click Apply to save the settings for that channel.
3. Click Copy.
4. Click the numbered boxes to indicate the channels you want to copy settings to, or click All to
copy to all channels.
5. Click OK.
#LX400111; r. 5.0/56647/56647; en-US 89
