Using the Main Menu15
4. Under Snapshot, select the number of snapshots the system will take when the snapshot but-
ton is pressed.
5. Click Apply.
6. (OPTIONAL) Click Copy to apply the settings for the current channel to one or more other
channels (see 15.12 Copying Settings to Another Channel, page 89 for full instructions on us-
ing the copy function).
15.6.3 Changing On-Screen Overlay
Remove or change the location of the date/timestamps and channel names. You can also change
channel names from this menu.
To change the on-screen overlay:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click CAMERA. Click the Overlay tab on the side panel, then Overlay on the top panel.
3. Select the channel you want to configure.
4. Click-and-drag the blue boxes on the camera image to adjust the location of the date/time and
channel name.
5. Use the checkboxes to enable/disable overlays. If needed, use the text field next to Channel
Name to adjust the channel name.
6. Click Apply.
7. (OPTIONAL) Click Copy to apply the settings for the current channel to one or more other
channels (see 15.12 Copying Settings to Another Channel, page 89 for full instructions on us-
ing the copy function).
15.6.4 Configuring Privacy Masking
A privacy mask blocks out a portion of the camera image with a black box, letting you have pri-
vacy in certain parts of a camera image. You can configure up to 4 privacy zones per channel.
To configure privacy masking:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
#LX400111; r. 5.0/56647/56647; en-US 64
