Active Deterrence13
2. Click EVENTS. Click the Event Settings tab on the side panel, then Deterrence on the top
panel.
3. Select the channel of a connected deterrence camera.
4. Check Enable.
5. Click Setup next to Warning Light to configure preferences:
• Duration: Choose how long the warning light will stay on when motion is detected.
• Select Warning Light for a solid white light, or Strobe for a flashing light. If you select
Strobe, set how quickly the light will flash under Strobe Frequency.
6. Click Setup next to Area to set an active area for automatic deterrence.
• The camera image appears with a grid overlay. The green area is the active area for
deterrence.
• Click or click-and-drag to add / remove boxes from the active area.
• In the example image above, only motion around the garage or on the porch will trigger the
warning light.
• Right-click when finished.
#LX400111; r. 5.0/56647/56647; en-US 46
