Lorex LHV2000 series User Manual

LHV2000 Series System
Specifications
24
System
Operating System Linux (embedded)
Pentaplex Simultaneous view, record, playback, backup & re-
mote monitoring
Number of Channels 4/8/16–channel — 1080p MPX, 720p HD, or ana-
log cameras supported
Inputs/Ouputs
Video IN
4/8/16 x 1Vp-p, CVBS, 75ohms, BNC
Video OUT
No
VGA OUT
Yes
HDMI Yes
Audio IN 1 Line in (RCA)
Audio OUT 1 Line out (RCA)
USB Port 1 at the back, 1 at the front
Alarm IN None
Alarm OUT
None
Video Output Resolution 1920x1080 (HDMI), 1280x1024, 1024x768
PTZ Control RS-485 Pelco D & P Protocol
Display
Live Display 4 ch: 1, 4
8 ch: 1, 4, 8
16 ch: 1, 4, 8, 9, 16
Live Display Speed 4 ch: 120 NTSC, 100 PAL
8 ch: 240 NTSC, 200 PAL
16 ch: 480 NTSC, 400 PAL
OSD ON/OFF
System Navigation USB mouse, IR remote controller, front panel
Motion Area Setting Adjustable grid (22x18)
Sensitivity Levels
100
Firmware Upgrade
Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization Auto time sync by NTP server
Recording
Video Compression
H.264
Audio Compression G.711
Recording Resolution NTSC: 1080p (1920x1080), 720p (1280x720),
960x480, 704x480, 352X480, 704x240, 352x240
PAL: 1080p (1920x1080), 720p (1280×720),
960×576, 704×576, 352×288
#LX400060; r.35927/36038; en-US
199
