Lorex LHV2000 series User Manual

LHV2000 Series System Specifications
24
Network Protocol HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP,
SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP
Filter
Network Interface 10/100-Base-TX, RJ-45
Network Speed Control 48Kb ~ 4096Kb/sec. per camera
General
Power Consumption Approx. 10 watts (No HDD Installed)
Supply Voltage LHV2104 / LHV2108: 100VAC-240VAC, 12VDC,
2A, 50/60Hz
LHV2116: 100VAC-240VAC, 12VDC, 3A, 50/60Hz
LHV2216: 100VAC-240VAC, 12VDC, 5A, 50/60Hz
Unit Dimensions (W x D x H) LHV2104 / LHV2108 / LHV2116:
12.8” x 10.0” x 2.2”
325mm x 255mm x 55mm
LHV2216: 14.8” x 11.5” x 1.8”
375mm x 292mm x 46mm
Unit Weight LHV2104 / LHV2108 / LHV2116: 3.3lbs / 1.5kg
LHV2216: 3.9lbs / 1.8kg
Operating Temperature 32° ~ 104° F / 0° ~ 40° C
Humidity 10 ~ 90% RH
Recording Resolution (Pixels) & Speed (FPS - Frames per second)
Model
FPS (NTSC/PAL)
720p
1280x720
1080p
1920x1080
LHV2104
Total 120/100 60/48
Per channel 30/25 15/12
LHV2108
Total 240/200 120/96
Per channel 30/25 15/12
LHV2116 / LHV2216
Total 480/400 240/192
Per channel 30/25 15/12
As our products are subject to continuous improvement, Lorex Corporation and its subsid-
iaries reserve the right to modify product design, specifications, and prices without notice
and without incurring any obligation. E&OE
#LX400060; r.35927/36038; en-US
