26. Handling and transportation mark
Figure1-27
27. Maintenance lubrication mark
Figure1-28
28. S ervice Lubrication table
Figure1-29
29. Safety b elt warning mark
Figure1-30
hen loading and unloading onto a truck, us
a loading and unloading platform. Pleas
strictly observe the following when using th
loading and unloading board.
1. Loading and unloading must be carrie
out according to the position shown in th
picture on the left. The length of loadin
and unloading board should be more than
times the height of truck (H).
(or risk tipping over).
2: please stop driving when operating i
front.
3. Do not adjust the direction on th
loading and unloadingboard.
4: please "turn off" switch when it i
automatic idling specification.
Do not go near the machine in case you ar
ressed under it when it tips over.
Service
Lubrication table
Add grease
Change engine oil
Change the hydraulic oil
Slewing support oil tank
Swing motor
Driving Motor
Replace
Interval of Service Time (h)
Note:
The first time to chang
oil and filter element is 5
hours
First replace rotary moto
and walking motor
Gear oil time is 500 hours
Radiator cooling water
engine oil, fuel oil
hydraulic oil and oil-wate
separator shall
inspected daily.
To reduce the number of deaths and injuries cause
by rollover accidents,
When installing a safety box,
Be sure to fasten your seat belt.
When the safety frame is damaged
here is no need to repair it.
Please replace it directly.
Warning
Note:
Warning
Blocker
4XH o
more
Roller gear oil
Guide wheel gear oil
Gear oil
Oil filter-element
Fuel filte
Radiator coolant
Air filter element
Filter element of hydraulic oil
To Next Page
