Operation
MultiPress S Operating manual 3.0 Rev 3.6.2009 41
6.4 Selecting and editing press profiles
To start a program or to change the parameters of a press profile, first the
desired press profile must be selected.
6.4.1 Selecting a press profile
› In the main menu, select the entry Profile.
› Press the ENT key.
"profiles" appears in the menu box.
› Select the menu item Select and press the ENT key.
"select" appears in the menu box.
› Select the desired press profile and press the ENT key.
The desired press profile is displayed in the profile box.
› Press the ESC key, to return to the Profiles menu.
fan temp.
Temperature in °C
Factory setting: 40°C
Change the digits using the
selection keys and confirm by
pressing the ENT key. After
confirming the last digit, you are
back in the Setup menu.
Active cooling stage (fan operating mode)
is finished when the temperature on the
press jaws has dropped to the fan
temperature.
Note: Do not set the fan temperature to a
smaller value than the ambient
temperature, since otherwise the cooling
stage will not be finished automatically.
service
Enter the 5-digit numeric code,
confirming each digit by pressing
ENT.
Test and calibration functions.
Changes not approved by LPKF can
result in malfunctions and damage to the
device.
They may only be carried out by
authorized personnel.
Menu item Selection options Function/Explanation
(Table page 2 of 2)
