6.5.3 Cooling the press system manually
In order to cool the press system quickly to the ambient temperature, for
example after a program cancel, the fan can be switched on manually.
› In the main menu, select the entry Start.
› Press the ENT key.
"start" appears in the menu box.
› Select the entry Fan on and press the ENT key.
Depending on equipment, the following information is displayed:
The cooling stage is finished automatically upon reaching the preset fan
temperature. A repeated acoustic signal will sound, and the message
"finished" will appear.
› Observe the information regarding the removal of the multilayer (see
chapter 6.6.4‚ "Removing the multilayer", on page 53).
Fig. 22: Display during the
cooling stage (with
automatic hydraulic
pump)
Fig. 23: Display during the
cooling stage (with
hand pump)
