Installation/Putting into operation
22 MultiPress S Operating manual 3.0 Rev: 3.6.2009
3.1.1 Placing the multilayer press
WARNING
Personal injury caused by excessive physical stress.
The MultiPress S weighs 170 kg (375 lbs). Lifting it manually can
overstress the spinal column and cause permanent damage.
For the installation of the MultiPress S, use a crane or a lifting
device.
Observe the maximum allowed loads.
WARNING
Danger caused by suspended loads.
The lifted press may fall down and cause serious injury.
When dismounting the shipping braces, protect the press against
falling down.
CAUTION
Risk of material damage.
The high weight of the press can result in damage when handled
improperly.
Do not tilt or knock the press nor subject it to excessive shaking.
Fig. 7: Removing shipping
braces from pallet,
inserting lifting ring
1 Removing the screws 2 Screwing in the lifting ring
1
