ProtoMat E34/E44
First startup
V. 1.0 | LPKF Laser & Electronics AG
41/78
Fig. 19: Loosening the locking screw
5. Pull the insertion tool (2) with the dummy tool downwards out of the collet.
Fig. 20: Extracting the dummy tool
6. Remove the dummy tool from the insertion tool.
Fig. 21: Dummy tool

The dummy tool has been removed from the collet.
