3 -32
▶ Before attaching, detaching or checking the PTO driven equipment, always place
the PTO switch in “OFF” position, and PTO gear lever in neutral position.
▶ If the PTO mode switch is placed in MANUAL position, the PTO shaft rotates
always regardless of the clutch pedal or position of the implement. Pay attention to
the surroundings to prevent an accident.
▶ Do not engage the PTO clutch at high engine speed. Sudden engagement can
cause damage to the implement and PTO clutch. Engage the PTO at low idle rpm,
and then raise the engine speed up.
Warning
(12) PTO switch
PTO mode switch
MHL
PTO mode switch
EHL
PTO switch
PTO switch
The engine starts only when the PTO switch is
placed in “OFF” position for safety.
After starting engine, you must comply with the
following instructions for PTO operation.
1. Check the safety conditions around the
implement.
2. Place the PTO gear lever to the desired position.
3. Select the PTO mode switch to “AUTO” or
“Manual” position.
4. Pull the PTO switch with pressing the lock
button of the switch to engage the PTO.
The PTO operation indicator will be ON.
5. If you want to stop the PTO temporarily while
operating, push the PTO switch in “OFF”
position. The PTO shaft will be stopped.
OFF
ON
