4 -8
Brake pedals
Clutch pedal
(3) Changing speed
Depress the clutch pedal fully and operate all the
shift levers correctly.
Before shifting F/R Shuttle lever, range gear
lever and creeper gear (if fitted), press down the
brake pedals and stop the tractor completely.
Set an appropriate driving speed according to
the road conditions.
Shuttle lever
Caution
▶ DO NOT depart from the tractor with the transmission gear placed in neutral
position and the parking brake is not applied. The tractor may roll down.
Apply the parking brake at all times before leaving the tractor.
▶ Remove the ignition key always after stopping engine.
Throttle pedal
1. Press the clutch pedal and brake pedals at
the same time to stop the tractor. Turn OFF
the key switch.
2. DO NOT release the clutch pedal until all
moving parts have been stopped.
(4) Emergency Stop
3. Apply parking brake.
Key switch
OFF
ON
Start
Parking brake lever
Park
Release button
To Next Page
