3 -24
3-2. Right-hand controls and Cabin pillar
Joystick lever
(Page 3-51)
Main gear
shift lever
Electrical power
outlet socket
4WD switch
Differential lock
switch
Wiper switch
Work light
switch
ECS switch
PTO mode
switch
Position control
lever
(Page 3-47)
Draft control
lever
(Page 3-48)
Remote control
Lever
(Page 3-50)
Auto lift switch
(Page 3-52)
Throttle lever
Parking brake lever
Throttle lever
Important to owner, read carefully (Mechanical Hydraulic Lift)
(1) Throttle lever
It is used to control the engine speed in field
operation.
DO NOT use this lever while driving on public
roads. Place the throttle lever to the Low speed
position and use the throttle pedal.
- Low speed : Pull the lever backward
- High speed : Push it forward.
There is a sensitive electric sensor on the
throttle lever. Do not remove/modify it arbitrarily.
To Next Page
