6 -6
6-5. Using Cut-off valve (if necessary)
When disassembling the air-conditioner hose
line, comply with the following instruction;
① Turn the plastic cap counter-clockwise and
remove it.
② Turn the high-pressure line valve (lower side)
clockwise and tighten it.
③ After starting engine and wait until for a about
30 seconds. Turn the low-pressure line valve
(upper side) clockwise and tighten it.
④ After stopping engine, remove the low-pressure
line.
⑤ Remove the high-pressure line.
When assembling the air-conditioner hoses,
comply with the reverse order of the
disassembly procedure.
▶When disassembling the air-
conditioner line, the refrigerant
may splash into your body.
Loosen the connection parts
slowly.
▶ Plug the disassembled hoses
with cap to protect them from
pollutants.
Caution
①
②
③
④⑤
To Next Page
