4 -9
(5) Stopping tractor
Caution
▶ DO NOT depart from the tractor with the transmission gear placed in neutral
position and the parking brake is not applied. The tractor may roll down.
Apply the parking brake at all times before leaving the tractor.
▶ Remove the ignition key always after stopping engine.
1. Press down the clutch pedal and brake
pedals. Pull the throttle lever to “Low” speed
position. Place the shuttle lever, main gear
shift lever in neutral position and PTO switch
to “OFF” position.
3. Apply parking brake and release the brake
pedals and clutch pedal slowly.
2. Lower the implements to the ground. Turn
key switch to “OFF” position.
Main gear
shift lever
Throttle lever
Position control lever
PTO switch
Brake pedals
Clutch pedal
Shuttle lever
Throttle pedal
Parking brake lever
Park
Release button
