5 -60
(8) Headlight bulb - Replace
▶ Be careful not to touch the bulb with bare fingers. Oil from the fingers can shorten
the life of bulb. Use protective cloth or glove when installing bulb.
▶ Bulb and surroundings are very hot while working. Be careful not to touch the bulb
with bare fingers. It may cause a burn of your hand. Before servicing the bulb, turn
off the light and cool down the bulb.
Caution
② Grille work light bulb
If a grille work light bulb② fails to operate, the
bulb must be replaced as below.
1. Open the tractor hood.
2. Remove the harness connector.
3. Turn the damaged bulb 1/4 turn counter-clock
wise and remove bulb from holder.
4. Insert a new bulb into the holder and turn 1/4
turn clockwise to secure.
5. Reinstall the harness connector.
NOTE: For about bulb specification, refer to the
chapter 5-6-(4) in this manual.
1
2
① Headlight bulb
If a headlight bulb① fails to operate, the bulb
must be replaced as below.
1. Open the tractor hood.
2. Remove the rubber grommet and harness
connector.
3. Unlatch the locking spring on the bulb and
remove the headlight bulb from the housing.
4. Insert a new bulb into the housing and install
the locking spring on the bulb to secure.
5. Reinstall the harness connector and rubber
grommet.
NOTE: For about bulb specification, refer to the
chapter 5-6-(4) in this manual.
1
2
