LS tractor MT563 User Manual

4 -4
▶ To stop the engine after finishing heavy work, run the engine for about 2 minutes at
low idle position. If you stop the engine suddenly, the engine life could be reduced.
Notice
▶When storing the tractor in cold weather, the battery must be removed and stored in
a cool, dry place that is not frozen away from children.
▶Allowing engine to idle for a long time will waste fuel and cause a build up of carbon.
Notice
Throttle lever
(2) Start in cold weather
 Pull the throttle lever to the low idle position.
 Start the engine after the cold start aid indicator
is turned off according to the right table.
 If the engine runs smoothly, carry out warm-up
for about 5~10 minutes at low idle position.
Especially for power shuttle model, be sure
to warm up the engine until blink of the
neutral indicator has disappeared on the
instrument panel.
 Use the engine oil for winter in cold weather.
Refer to “Lubricants and Capacity” at the end of
this manual.
 Use the diesel for winter when it is very cold
weather. It is much easier to start the engine.
Coolant Temp. Preheat time(s)
60℃(140℉)
0
40℃(104℉)
0
30℃(86℉)
0
20℃(68℉)
8
10℃(50℉)
15
0℃(32℉)
18
-10℃(14℉)
25
-20℃(-4℉)
30
-30℃(-13℉)
40
Caution
▶ Safety Interlock !
When the ambient temperature is lower than 20℃, the engine speed will not be
increased over 1400 rpm for about maximum 1 minute. But, it is normal operation to
prevent an engine failure in cold weather.
(3) Engine stop
 Place all the transmission gear levers or
switches in the “NEUTRAL” or “OFF” position.
 Pull the throttle lever backward to reduce the
engine speed and turn the key switch to the
“OFF” position. The engine will be stopped.
 Remove the ignition key after stopping engine.
