5 -51
(4) Fuse & Main fuse
Cabin fuse
box cover
① Cabin fuse box
Cabin fuse box is installed on the right cabin
filler.
How to replace the fuse
1. Remove the fuse box cover.
2. Check if each fuse is damaged or not.
3. Replace it with a new one of the same capacity
as the damaged fuse.
Capacity and function of each fuse is described
on the fuse box cover.
< Cabin fuse box (Cabin type) >
▶If the same function fuse is damaged repeatedly, contact your authorized local
dealer for check. Do not use a substitute such as wire or aluminum foil.
▶If using the substitute instead of the rated capacity fuse, it may cause a fire which
results in damage of the tractor or serious injury.
Caution
