4 -7
Position control
lever
Throttle pedal
Clutch pedal
Brake pedals
Power shuttle lever
Throttle lever
Parking brake
lever
Main gear
shift lever
1. Lift up all the implements
(front/middle/rear) from the ground
after starting engine.
2. Pull the throttle lever to the low
speed position.
3. Place the power-shuttle lever in
neutral position.
4. Place the transmission gear levers
(Main, Range, Creeper gear lever)
on a suitable position.
5. Press down the brake pedals and
release the parking brake lever.
6. Place the power-shuttle lever to
forward/reverse position, and press
down the throttle pedal slowly when
the vehicle begins to start.
▶When starting power-shuttle model normally, use the power-shuttle lever without
depressing clutch pedal.
Notice
② Power-shuttle model
