4 -30

Unit : mm (inch)

② Front wheel track – 11.2-24 8PR with rim & disk (W10x24)

N/A

1577(62.1in)

(Standard track)

1777(70.0in)

1774(69.8in)

1667(65.6in)

1665(65.6in)
