LSIS S100 Series User Manual

Chapter 4. Basic Features
15
Setting a Frequency Reference for -10–10V Input
Set the Frq (Frequency reference source) code in the Operation group to 13 (V3), and then set code 02
(V3 Polarity) to 1 (bipolar) in the APO group (Ao). Use the output voltage from an external source to
provide input to V3
[V3 terminal wiring]
[Bipolar input voltage and output frequency]
Group Code Name LCD Display
Parameter
Setting
Setting
Range
Unit
Operation Frq
Frequency reference
source
Freq Ref Src 13 V3 0–16 -
In 01
Frequency at
maximum analog
input
Freq at 100% 60.00
0– Max
Frequency
Hz
Ao
0
1
V3 input monitor
V
3
Monitor
0.00
0.00
–
12.00V
V
0
2
V3 polarity options
V
3
Polarity
1
Bipolar
0
–
1
-
10
V3 minimum input
voltage
V3- volt x1 0.00 10.00–0.00V V
11
V3 output at minimum
voltage (%)
V3- Perc y1 0.00 -100.00–0.00% %
12
V3maximum input
voltage
V3- Volt x2 -10.00 -12.00 –0.00V V
13
V3 output at maximum
voltage (%)
V3- Perc y2 -100.00 -100.00–0.00% %
V3
CM
