LSIS S100 Series User Manual

Chapter 5. Table of Functions
41
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
46
18
0h132E
Brake engage
delay time
BR Eng Dly 0.00-10.00(s) 1.00 X/A O O
47
18
0h132F
Brake engage
frequency
BR Eng Fr
0.00
-
Maximum
frequency(Hz)
2.00 X/A O O
50 0h1332
Energy saving
operation
E-Save Mode
0
None
0:None X /A O X
1
Manual
2 Auto
51
19
0h1333
Energy saving
level
Energy Save 0-30(%) 0 O/A O X
60 0h133C
Acc/Dec time
transition
frequency
Xcel Change
Fr
0.00-Maximum
frequency(Hz)
0.00 X/A O O
64 0h1340
Cooling fan
control
FAN Control
0
During Run
0:Durin
g Run
O/A O O
1
Always ON
2
Temp Control
65 0h1341
Up/down
operation
frequency save
U/D Save
Mode
0
No
0:No O/A O O
1 Yes
66 0h1342
Output contact
On/Off control
options
On/Off Ctrl Src
0
None
0:None X/A O O
1
V1
3
V2
4
I2
6
Pulse
67 0h1343
Output contact
On level
On-Ctrl Level
Output contact off
level- 100.00%
90.00 X/A O O
68 0h1344
Output contact
Off level
Off-Ctrl Level
-
100.00
-
output
contact on level
(%)
10.00 X/A O O
70 0h1346
Safe operation
selection
Run En Mode
0
Always
Enable
0:Alway
s Enable
X/A O O
1
DI
Dependent
71
20
0h1347
Safe operation
stop options
Run Dis Stop
0
Free
-
Run
0:Free-
Run
X/A O O
1
Q
-
Stop
2
Q
-
Stop
Resume
72
20
0h1348
Safe operation
deceleration time
Q-Stop Time 0.0-600.0(s) 5.0 O/A O O
74 0h134A
Selection of
regeneration
evasion function
for press
RegenAvd Sel
0
No
0:No X/A O O
1 Yes
75 0h134B
Voltage level of
regeneration
evasion motion
RegenAvd
Level
200V : 300
-
400V
350
X/A O O
400V : 600-800V 700
19
Displayed if Ad.50 is not set to 0 (None).
20
Displayed when Ad.70 is set to 1 (DI Dependent).
