LSIS S100 Series User Manual

Chapter 5. Table of Functions
50
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
input terminal
O
ff
filter
87 0h1557
Multi-function
input
contact selection
DI NC/NO Sel
P
7
–
P1
0
0000
39
X/A O O
0
A contact (NO)
1
B contact (NC)
89 0h1559
Multi
-
step
command
delay time
InCheck Time 1-5000(ms) 1 X/A O O
90 0h155A
Multi-function
input terminal
status
DI Status
P
7
–
P1
0
0000
39
-/A O O
0
release(Off)
1
Connection (On)
91 0h155B
Pulse input
amount display
Pulse Monitor
(kHz)
0.00-50.00(kHz) 0.00 -/A O O
92 0h155C
TI input filter time
constant
TI Filter 0-9999(ms) 10 O/A O O
93 0h155D
TI Minimum
input pulse
TI Pls x1 0.00-32.00(kHz) 0.00 O/A O O
94 0h153E
TI
o
utput at
Minimum pulse
(%)
TI Perc y1 0.00-100.00(%) 0.00 O/A O O
95 0h155F
TI Maximum
input pulse
TI Pls x2 0.00-32.00(kHz) 32.00 O/A O O
96 0h1560
TI Output at
Maximum pulse
(%)
TI Perc y2 0-100(%) 100.00 O/A O O
97 0h1561
TI rotation
direction change
TI Inverting
0 No
0:No O/A O O
1
Yes
98 0h1562
TI quantization
level
TI Quantizing 0.00
35
, 0.04-10.00(%) 0.04 O/A O O
99 0h1563
SW1(NPN/PNP)
SW2(V1/V2[I2])
status
IO SW State
Bit
00~11
00 -/A O O
00
V
2
, NPN
01
V2
,
PNP
10
I2, NPN
11
I2, PNP
39
The initial value 0000 will be displayed on the keypad as . The 7-seg screen of extension I/O
displays in case of clicking left and right key
