LSIS S100 Series User Manual

Chapter 5. Table of Functions
49
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
function setting
1 Fx
66 0h1542
P2 terminal
function setting
P2 Define 2 Rx 2:Rx X/A O O
67 0h1543
P3 terminal
function setting
P3 Define 3 RST 5:BX X/A O O
68 0h1544
P4 terminal
function setting
P4 Define 4 External Trip 3:RST X/A O O
69 0h1545
P5 terminal
function setting
P5 Define 5 BX 7:Sp-L X/A O O
70 0h1546
P
6
terminal
function setting
P6 Define 6 JOG 0 : No X/A O O
71 0h1547
P
7
terminal
function setting
P7 Define 7 Speed-L 0 : No X/A O O
72 0h1548
P
8
terminal
function setting
P8 Define 8 Speed-M 0 : No X/A O O
73 0h1549
P
9
terminal
function setting
P9 Define 9 Speed-H 0 : No X/A O O
74 0h154A
P
10
terminal
function setting
P10 Define 11 XCEL-L 0 : No X/A O O
12
XCEL
-
M
13
RUN Enable
14
3
-
Wire
15
2nd Source
16
Exchange
17
Up
18
Down
20
U/D Clear
21
Analog Hold
22
I
-
Term Clear
23
PID Openloop
24
P
Gain2
25
XCEL Stop
26
2nd Motor
34
Pre Excite
38
Timer In
40
dis Aux Ref
46
FWD JOG
47
REV JOG
49
XCEL
-
H
50
User Seq
51
Fire Mode
54
TI
38
85 0h1555
Multi
-
function
input terminal On
filter
DI On Delay 0-10000(ms) 10 O/A O O
86
0h1556
Multi
-
function
DI Off Delay
0
-
10000(ms)
3
O/A
O
O
38
Displayed when P5 is selected on Px terminal function.
