LSIS S100 Series User Manual

Chapter 5. Table of Functions
64
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
06 0h1B06
Input voltage
range during
open-phase
IPO V Band 1-100(V) 15 X/A O O
07 0h1B07
Deceleration time
at fault trip
Trip Dec Time 0.0-600.0(s) 3.0 O/A O O
08 0h1B08
Selection of
startup on trip
reset
RST Restart
0 No
0:No O/A O O
1 Yes
09 0h1B09
Number of
automatic restarts
Retry Number 0-10 0 O/A O O
10
53
0h1B0A
Automatic restart
delay time
Retry Delay 0.0-60.0(s) 1.0 O/A O O
12 0h1B0C
Motion
at speed
command loss
Lost Cmd
Mode
0 None
0:None O/A O O
1 Free-Run
2 Dec
3 Hold Input
4 Hold Output
5 Lost Preset
13
54
0h1B0D
Time to
decide
speed command
loss
Lost Cmd Time 0.1-120(s) 1.0 O/A O O
14
54
0h1B0E
Operation
frequency
at speed
command
loss
Lost Preset F
Start frequency-
Maximum
frequency(Hz)
0.00 O/A O O
15
54
0h1B0F
Analog input
loss decision level
AI Lost Level
0 Half x1
0:Half of
x1
O/A O O
1 Below x1
17 0h1B11
Overload warning
selection
OL Warn Select
0 No
0:No O/A O O
1 Yes
18 0h1B12
Overload alarm
level
OL Warn Level 30-180(%) 150 O/A O O
19 0h1B13
Overload warning
time
OL Warn Time 0.0-30.0(s) 10.0 O/A O O
20 0h1B14
Motion at overload
fault
OL Trip Select
0 None
1:Free-
Run
O/A O O
1 Free-Run
2 Dec
53
Displayed when Pr.09 is set higher than 0.
54
Displayed when Pr.12 is not set to 0 (NONE).
