LSIS S100 Series User Manual

Chapter 5. Table of Functions
65
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
21 0h1B15
Overload fault
level
OL Trip Level 30-200(%) 180 O/A O O
22 0h1B16 Overload fault time OL Trip Time 0.0-60.0(s) 60.0 O/A O O
25 0h1B19
Underload
warning selection
UL Warn Sel
0 No
0:No O/A O O
1 Yes
26 0h1B1A
Underload
warning time
UL Warn Time 0.0-600.0(s) 10.0 O/A O O
27 0h1B1B
Underload fault
selection
UL Trip Sel
0 None
0:None O/A O O 1 Free-Run
2 Dec
28 0h1B1C
Underload fault
time
UL Trip Time 0.0-600.0(s) 30.0 O/A O O
29 0h1B1D
Underload
lower
limit level
UL LF Level 10-30(%) 30 O/A O O
30 0h1B1E
Underload upper
limit level
UL BF Level 30-100(%) 30 O/A O O
31 0h1B1F
No motor motion
at detection
No Motor Trip
0 None
0:None O/A O O
1 Free-Run
32 0h1B20
No motor
detection current
level
No Motor Level 1-100(%) 5 O/A O O
33 0h1B21
No motor
detection delay
No Motor Time 0.1-10.0(s) 3.0 O/A O O
40 0h1B28
Electronic thermal
fault selection
ETH Trip Sel
0 None
0:None O/A O O
1 Free-Run
2 Dec
41 0h1B29
Motor cooling fan
type
Motor Cooling
0 Self-cool
0:Self-cool O/A O O
1 Forced-cool
42 0h1B2A
Electronic thermal
1 minute rating
ETH 1min 120-200(%) 150 O/A O O
43 0h1B2B
Electronic thermal
continuous rating
ETH Cont 50-150(%) 120 O/A O O
45 0h1B2D BX trip mode BX Mode
0 Free-Run
0 X/A O O
1 Dec
50 0h1B32
Stall prevention
motion and flux
braking
Stall Prevent
bit 0000-1111
1000 X/A O O
000
1
Accelerating
001
0
At constant
speed
