MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page 1-9
Using SPM
!If you do not have a hard drive, insert the SPM diskette into Drive A
and switch to Drive A if it is not already the current drive.
!Start the SPM program.
Console Display/Instructions Additional Information PC
Type
630. The SPM Welcome screen appears, as shown below.
!Press any key.
!Select an option by pressing one of the function keys.
With a Local or Remote Modem Connection
When the equipment is set up, you can perform remote maintenance by dialing
the remote processor’s built-in 2,400/1,200-bps modem using Remote Access.
You can dial the modem directly or call the system operator and request to be
transferred to the modem. In Release 6.0 and later systems (Hybrid/PBX mode)
where systems are private networked and only one system has public switched
networked trunks, you must use the Remote Access feature in order to access
the system with public switched networked trunks and from that system reach
any switches connected to it directly or indirectly via tandem trunks. All three
procedures are explained below.
:HOFRPHWR630
If the main menu (see Step 4) does
7KH0(5/,1/(*(1'
not appear, or if the information on
6\VWHP3URJUDPPLQJ
the screen is garbled, press any
0DLQWHQDQFH8WLOLW\
key again.
3OHDVHSUHVVDQ\NH\
WRFRQWLQXH
9HUVLRQ;[[
6300DLQ0HQX
0HQX6HOHFW)XQFWLRQ

6\V3URJUDP 0DLQWHQDQFH


%DFNXS 5HVWRUH


%RDUGV 3DVV7KUX


3ULQW2SWV 3DVVZRUG


0RQLWRU /DQJXDJH

