MODEL 9DP-1 Operator’s Manual
Ludlum Measurements, Inc. 31 December 2015
same. The units assigned in the “Integrate” feature have no effect on the
“Integrated Dose” function unless the view element does not have an
appropriate unit assigned. Only then will the “Integrated Dose” function rely
upon the “Integrate” feature units for proper calculation.
Note: The “Integrated Dose” function grants the user the ability to reset
the integrated dose collected by the instrument; however, the “Integrate”
feature controls whether the integrated dose is functioning or not. If the
“Integrate” feature is “Off,” no data updates will be displayed by the
“Integrated Dose” function.
Value
“Value” represents the current numerical value of the integrated dose given
the supplied multiplier and units. “Value” is a non-editable field.
Multiplier
“Multiplier” represents the current multiplier associated with the integrated
dose. “Multiplier” is a special field with valid values of micro, milli, unity, kilo,
and mega.
Units
“Units” represents the current units associated with the integrated dose.
“Units” is a special field with valid values of “R,” “Sv,” “Gy,” and “REM.”
6.4.2 Data Logging
“Data Logging” is a sub-menu which grants access to the “Power Up Mode,”
“Operating Mode”, and settings associated with the data logging feature.
Power Up Mode
“Power Up Mode” represents the state in which the data logging feature will
operate when power is applied to the instrument and is a special field.
The definitions of the data logging power-up modes are:
Default: was pre-defined by Ludlum Measurements and is “Off.”
Last: indicates that the instrument will power up in the same “Operating
Mode” the instrument was using at the time the instrument was last
powered down.
Off: This mode turns the data logging feature “Off.”
On: This mode turns the data logging feature “On.”
