2.3 SETUP
The SETUP is divided into two parts, First level (non system data) and the Second level (system data). Inputs
done in the first level are connected with daily work, the settings done in the second level may change system
characteristics and as such are significant.
2.3.1 Main Setup (First level)
All options are selected with the UP/DOWN () switch and can be entered at any time;
The system settings are not affected. The Menu has six items, starting with QNH Reserve
and ending with System which allows entry into system setup.
Once the desired option has been selected, press ENTER to access the sub-menu.
2.3.1.1 QNH RES (QNH and Safety Altitude input)
Input Procedure:
• Use the UP/DOWN selector to choose the item it is required to change
(QNH, ALT.R.)
• Press ENTER
• Use UP/DOWN to select the value required and press ENTER to input it
• Once all changes are complete, press ESC top return to SETUP menu
ALT.R : This setting is used to input the altitude reserve or safety altitude. Setting 0 means that no
altitude reserve is set for the final glide. After input the final glide is shifted and the arrival is calculated to the
altitude set in the reserve menu.
Note!
Even after input of a reserve the final glide director will show you 0 glide deviation if the glider position is on the
shifted glide.
Finish line arrival on 0 m
Finish line arrival on 200 m
Note!
Some settings are so called global settings, not connected to pilot and
second parts are so called local settings. Local settings belong to pilots.
Local settings are accompanied with a man silhouette which to make
understanding more easy.
