Lynx
®
NGT-9000
Pilot’s Guide1-14
Description
EQUIPMENT DESCRIPTION
The Lynx NGT-9000 MSS family consists of the following standard and
optional equipment. Refer to the Aircraft Flight Manual Supplement to
determine what optional equipment is installed. Chapter 3 provides a
list of optional cockpit switches and lamps.
Required Equipment
GPS Antenna
L-Band (978MHz/1030/MHz/1090MHz) Antenna
Detachable Configuration Module (DCM)
Optional Equipment
Directional Antenna (required for TAS operation)
Additional L-Band Antenna (required for diversity operation)
Traffic Display
Weather Display
WiFi Serial Adapter and Personal Electronic Device (PED)
CP-2500 Control Panel (Required for the remote mount version)
GPS Antenna and Internal GPS Receiver
The GPS utilizes signals from Global Positioning System (GPS)
satellite constellation and Satellite-Based Augmentation Systems
(SBAS). The Lynx NGT-9000 have an internal GPS function that
provides position, velocity, time and integrity (NIC, NAC etc) informa-
tion to the ADS-B functions. The antenna is located on the top of the
aircraft.
L-Band Antenna
The L-Band antenna is used by the Lynx NGT-9000 to receive
1030MHz, receive and transmit 1090MHz and receive 978MHz. It is
located on the bottom of the aircraft.
A second L-Band antenna is installed on the top of the aircraft for
models with Diversity.
Detachable Configuration Module (DCM)
The DCM is a solid-state device that retains software and hardware
configuration information. It is permanently attached to the aircraft
via the wiring harness and communicates with Lynx NGT-9000 via
serial bus. Configuration options are set up during installation. The
configuration data that is saved on the DCM are as follows: DCM
configuration version, configuration, input / output interface options,
aircraft specific options, and installation calibration parameters.
•
•
•
•
•
•
•
•
•
