Pilot’s Guide1-2
Description
Part Number: 9029000-20000 (panel mount)
Size: Fits into a standard MARK 6.25 in width panel.
Weight: 2.96 Lbs Nominal.
Power
Requirements:
+14.0 VDC nominal or +28.0 VDC nominal.
19.0 watts nominal, 24.0 watts maximum
Display
Luminance:
Range 0.05 fl to 150 fl
Start Up Time On Ground 20 seconds or less
In air 5 seconds or less.
Built In Test: Fault Monitoring on all stages of operation from
start up to power down.
Interfaces: ARINC 429, RS-422, RS-232, Discrete In-
put/Outputs, RF Suppression Bus, and DCM
serial interface .
Functionality: Mode S Transponder (1030/1090)
Global Positioning System (GPS)
ADS-B Receive: (1090ES/UAT)
ADS-B Transmit: (1090ES)
TIS-B (1090ES)
FIS-B (UAT)
Mode S Transponder Diversity (optional)
(1090ES)
Traffic Awareness System (TAS) (optional)
•
•
•
•
•
•
•
•
Service Life: Unlimited.
Scheduled
Maintenance:
The Lynx NGT-9000 is a transponder device and
must be tested and inspected every 24 months
subject to the requirements of FAA documents
91.413.
Repairs: Repairs performed at the FAA certificated Re-
pair Station co-located at the OEM (equipment)
facility.
Compliance: The Lynx NGT-9000 has been shown to meet
the requirements in TSO-C166b and meets the
requirements of 14 CFR 91.225a installed in
accordance with these installation instructions.
SPECIFICATIONS

Lynx NGT-9000 Series Specifications

General

Type	Avionics Display
Display	LCD
Operating Temperature	-20°C to +55°C
Interface	ARINC 429, RS-232
ADS-B	ADS-B In/Out
