Pilot’s Guide 3-7
Controls and Indicators
ADS-B SYSTEM FAIL: The ADS-B out is not being transmitted by
the Lynx NGT-9000.
GPS FAIL: The GPS derived position input is not functioning.
IDENT: The IDENT message is being sent by the Lynx NGT-9000
via ADS-B Out.
GPS INIT: GPS Initialization –The GPS contained within the Lynx
NGT-9000 is not ready.
NO ADS-B COVERAGE: No ground based transceiver has
acknowledged the presence of the Lynx NGT-9000 in the system.
XPNDR: The transponder function of the Lynx NGT-9000 has
failed.
•
•
•
•
•
•

Lynx NGT-9000 Series Specifications

General

Type	Avionics Display
Display	LCD
Operating Temperature	-20°C to +55°C
Interface	ARINC 429, RS-232
ADS-B	ADS-B In/Out
