Lynx NGT-9000 Series User Manual

Lynx
®
NGT-9000
Pilot’s Guide5-2
Principles of TAS Operation
Table 5-1: General Display Conditions
for the Panel Mount Lynx NGT-9000
indication deScriPtion
Traffic Unavailable
(Amber text)
ADS-B is operational but heading
and track are invalid.
GPS is failed.
TAS is in Standby.
Transponder Mode Control is “ON”
which inhibits the display of relative
altitude so traffic is unavailable.
•
•
•
•
TAS STBY
(Models with TAS only)
A traffic mode indicator that is shown
when the Traffic Awareness (TAS)
system is in standby.
TAS ONLY
(Models with TAS only)
A traffic mode indicator that is shown
when TAS is in operation, but ADS-B
is unavailable.
ADS ONLY
(Models with TAS only)
A traffic mode indicator that is shown
when TAS is failed (or not available)
and ADS-B is available.
Initializing The indication is shown on the weath-
er map (FIS-B application screen).
It continues to be shown until internal
operations have completed.
Map Fail The indication is shown on the weath-
er map (FIS-B application screen).
It is shown when a fault is detected
that prevents the FIS-B data from
showing on the screen.
TRK (Track) Indicates that the traffic display
orientation is true track.

Lynx NGT-9000 Series Specifications

General

Type	Avionics Display
Display	LCD
Operating Temperature	-20°C to +55°C
Interface	ARINC 429, RS-232
ADS-B	ADS-B In/Out
