MacDon D65 - 3.6 Header Setup; 3.6.2 Header Settings

214328 56 Revision A
Figure 5.10: Tensioning Belt
4. Insert a long punch (or equivalent) into hole (A) in
idler bracket.
5. Pry downward until a force of 27 N (6 lbf) deflects timing
belt 13 mm (1/2 in.) at midspan as per 2, page 55.
Figure 5.11: Knife Drive
6. Tighten nuts (A) on idler mounting bracket.
7. Close endshield(s). Refer to 3.7 Closing Endshield,
page 29.
PERFORMING PREDELIVERY CHECKS
