Network Wiring (Optional)
Please refer to the appropriate Network manual (AirLynk, Controller 4, Controller 10/20/30) for
all network wiring instructions. Only use the green CAT5e cable provided by EnergyLogic.
Controller
CAT5e Cable
(100ft / 30.5m)
CAT5e Cable
(100ft / 30.5m)
Wall Plug
