4.1 Drive Installation
Ensure ground wire
is properly attached
High Voltage DriveLow Voltage Drive
Note: Model numbers ending with an “H” are high voltage while model
numbers ending with an “L” are low voltage.
WARNING: POWER ABOVE 252 VAC WILL DESTROY A LOW VOLTAGE DRIVE
CAUTION: RISK OF ELECTRIC SHOCK. The bus capacitors discharge
to a level below 50V DC in 1 minute.
