6x
1.3 All Fixed Angle Mounts
Motor Unit
Warning: The fan must be lifted by the struts. Do NOT lift the fan by the drive.
Remove six (6) screws and the bottom cover. Be careful not to damage
the electrical components with the cover removed.
Two people can lift the fan if a lift is not available.
Must use Guy Wire Brackets when installing the Fixed Angle Mount
L3 L2 L1
To Next Page
