24.2 Universal Mount
Glulam Safety Cable
Tighten both nuts
7 1/2 ft-lbs [10.2 N-m]
Complete safety cable installation and turn to page 47
WARNING: Do not put too much tension on the safety cable. There
needs to be a small amount of slack present in the safety cable for
proper functioning. Avoid sharp edges.
Run safety cable
Run safety cable
though hole
To Next Page
