© 2019 EnergyLogic, LLC Toll Free: 800 311 8828 Fax: 615 471 5202 www.energylogic.com 5
Rev. Date 040819
Fusing Chart
BRANCH CIRCUIT PROTECTION IS REQUIRED TO PROTECT THE ELECTRICAL COMPONENTS
AND COMPLY WITH UL 507.
Use the table below to select the correct fast acting fuse size for your application. The optional
fuse disconnect switch provided by EnergyLogic uses class gG fast acting fuses. Fuses must be
purchased separately.
Max Amp Draw / Recommended Fuse
Voltage and Phase 10ft 12ft 14ft 16ft 18ft 20ft 24ft
208-240 VAC 1-Phase 3.5A / 6 3.7A / 6 4.3A / 6 3.2A / 6 4.5A / 6 5.7A / 8 6A / 8
208-240 VAC 3-Phase 2.5A / 4 2.6A / 4 2.9A / 4 2.4A / 4 3A / 4 3.6A / 6 3.8A / 6
480 VAC 3-Phase 1.1A / 4 1A / 4 1.3A / 4 1A / 4 1.3A / 4 1.8A / 4 1.7A / 4
Reference page 57 for installation.
Part Numbers:
4A 6A 8A
MERSEN FUSES FR10GG50V4 FR10GG50V6 FR10GG50V8
EATON FUSES C10G4 C10G6 C10G8
DF FUSES 420004 420006 420008
URLs for
Mersen fuses:
http://ep-us.mersen.com/products/catalog/line/ferrule-fuse-links-10x38-gg-400-to-690vac/
Eaton Fuses:
http://www.cooperindustries.com/content/public/en/bussmann/electrical/products/iec_
british0/class_gg_gl_ferrulefuses/class_gg_gl_ferrulefuses10x38mm.resources.html
DF Fuses:
http://www.df-sa.es/products/cylindrical/gg-fuse-links
